Inverted Microscope

Optical system

Infinity color correction system

Viewing head

20~45 degree tilting binocular head,inverted image,interpupilary distance:50~76mm

Eyepieces

High eye-point plan eyepiece PL10X/22mm,diopter adjustable,

Objectives

LWD plan semi-APO objectives(2X/4X/10X/20×/40X/60X

LWD plan semi-APO phase contrast objectives(4×/10×/20×/40×/60X)

Infinity plan apochromatic objectives(2X14X/10×/20X140X/60X/60X oil/100X)

Infinity plan super apochromatic objectives(10X/20X/40X/60Xoil)

Nosepiece

Electric bright field sextuple nosepiece with DIC slot

Frame

Low position coarse and fine coaxial electric focusing mechanism,range:10.5mm,precision:1μm.

Built-in electric left camera port,splitting ratio:0:100/50:50/100:0;dual optical path,

with fluorescent light barier.

Stage

Manual mechanical stage,size:300mm(X)×240mm{Y,moving range:135mm(X)×85mm(Y),stage thickness:30mm.Right universal handle,XY axis limitable and lockable,moving range 50mm×50mm; with φ110mm replaceable disc

Condenser

Manual 7 positions Condensor with NA 0.55,WD=27mm;3 positions for a30mm(Phase contrast observation).

4 positions for a38mmDIC).;support Bright field,Phase Contrast,Dark field,Polarizing.DIC observation.

Super long working distance condenser with more than 4 holds,NA≥0.3,WD≥73mm;  support   for   4X-60×phase   contrast   or   10X-40×RPC

Transmisson lllumination

illar tilt mechanism,Koehler Transmisson illuminator, Condensor holder with 65mm stroke;4 filters holders; with LBD/Green filter/Neutral filter;

Fluorescent System

Manual turret system with 8fiters,Manual shutter,L type fluorescence attachment,with fluorescence filters:B1/G1/UV1

Lamp house

100W Hg lamp house,Power supply,100W Hg lamp(OSRAM)

10W LED lamp house

Camera

SOPTOPOD series cameras for option,with MV Image 3.0 software

Optional

0.5X/0.65X/1XC-mount adapters,focus adjustable;System controller;TPC;PC and monitor; Centering eyepiece;phase contrast &DIC attachment;Professional software
