Binocular Biological Microscope
Max Magnification:100X
Specification:
Optical System | Infinity color corrected optical system |
View Head | 30°inclined,gemel binocular head,interpupillary distance 47mm-75mm |
30°inclined,gemel trinocula head,interpupillary distance 47mm-75mm,light spiting ratio R:T=8:2 | |
Eyepiece | high eye point wide field plan eyepiece PL10X/18mm,with adjustable diopter |
high eye point wide field plan eyepiece PL10X120mm,with adjustable diopter | |
Objective | Infinity planachromatic objective (4X、10X、20X、40X、60X、100X) |
Infinity plan positive phase contrast objective(10X、20X、40X、100X) | |
Nosepiece | reversed quadruple/quintuple nosepiece |
FocusingMechanism | low position coaxial focusing mechanism,coarse range:25mm,fine precision:0.002mm,with tension adjustment and upper limit |
Stage | 150mm×140mm double-layer composite mechanical moving stage,double slice clamps,moving range:76mm x 50mm;accuracy:0.1mm (triangular guide rail) |
150mm ×162mm double-layer composite mechanical moving stage,double slice clamps,moving range:76mm ×50mm;accuracy:0.1mm(X-axis single rail driving)without rack protruding structure,stage surface with wear resistant and corrosion resistant treatment | |
Transmission Illumination System | N.A.1.25 compound eye illumination condenser group (with plug-in phase contrast and dark field accessories' interface),condenser preset center,optional lifting function,adaptive 100V-240V switching power supply,single high brightness 3W LED (cold/warm color optional,cold color temperature 4750K-5500K,warm color temperature 2850K-3250K)(preset center),light intensity can be continuously adjusted |
Camera Adapter | 0.35X/0.5X/0.65X1XC-mount adapter,focusing adjustable |
Others | polarizers,analyzers,colour filters,filters,phase contrast panels,dark field panels |
Diagram:
| Model | VB2018 |
| Optical System | Finite Color Corrected Optical System |
| Viewing Head | 30°inclined binocular viewing head; interpupillary distance: 50mm~75mm; single diopter adjustable |
| Eyepiece | High eye point wide filed WF10x/18mm, or plan eyepiece PL10X/18mm(with pointer for option) |
| Objective | Achromatic objective 4X/10X/40X/100X |
| Plan achromatic objective 4X/10X/20X/40X/100X | |
| Nosepiece | Quadruple nosepiece |
| Quintuple nosepiece | |
| Frame | Integrated design, coaxial focus system with upper limited and tension adjustment, coarse range: 28mm; fine precision: 0.002mm; provided with an adjustable tightness device to prevent slipping and a mechanical upper limit device |
| Stage | 140mm*132mm double layers stage, moving range: 76mm*50mm, precision: 0.1mm |
| Condenser | N.A.1.25 ABBE Condenser and Iris Diaphragm |
| Illumination | Wide voltage 100V~240V, intensity adjustable by power switch, 3W LED, bulb center preset |
